Model |
Ci130QR |
Nominal impedance |
8Ohm |
Sensitivity (2.83V @ 1m) |
87dB |
Frequency response +/-6dB open-backed |
45Hz - 34kHz |
Crossover frequency |
3.8kHz |
Drive units |
LF: 130mm (5.25in.) MF: - HF: 19mm (0.75in.) |
Recommended amplifier power |
10-100W |
Product external dimensions |
Diameter Ø: 193.4mm (7.61in.) Depth: 83mm (3.28in.) |
Cut-out dimension |
Diameter: 158mm (6.22in.) |
Mounting depth from surface |
Product only: 77.8mm (3.06in.) |
Optional rough in frame |
RIF130R |
