| Model |
Ci160QR |
| Nominal impedance |
8Ohm |
| Sensitivity (2.83V @ 1m) |
89dB |
| Frequency response +/-6dB open-backed |
38Hz - 34kHz |
| Crossover frequency |
3.0kHz |
| Drive units |
LF: 160mm (6.5in.) MF: - HF: 19mm (0.75in.) |
| Recommended amplifier power |
10-125W |
| Product external dimensions |
Diameter Ø: 234.6mm (9.24in.) Depth: 98mm (3.86in.) |
| Cut-out dimension |
Diameter Ø:196mm (7.71in.) |
| Mounting depth from surface |
Product only: 91mm (3.58in.) |
| Optional rough in frame |
RIF160R |
