| T301 / T301c |
|
| Design |
Two and a half-way closed box |
| Drive units |
2 x 115mm (4.5in.) dual layer MF
25mm (1in.) aluminium HF |
| Frequency response |
80Hz - 30kHz |
| Crossover frequency |
1.7kHz |
| Amplifier requirements |
10 - 150 W |
| Sensitivity (2.83V/1m) |
91dB (wall mount)
88dB (floor stand mount) |
| Maximum output (SPL) |
110dB |
| Impedance |
8Ω |
| Internal volume |
1.4 Litres |
| Weight |
1.5kg (3.3lbs) |
Dimensions
(H x W x D) |
600* x 140 x 35 mm
(23.6 x 5.5 x 1.4 in.) |
Dimensions
(H x W x D)
centre mode |
140 x 600 x 35 mm
(5.5 x 23.6 x 1.4 in.) |
| * Height of satellites will increase by 30mm when using supplied desk stand |
| |
|
| T101 |
|
| Design |
Two-way closed box |
| Drive units |
115mm (4.5in.) dual layer MF
25mm (1in.) aluminium HF |
| Frequency response |
80Hz - 30kHz |
| Crossover frequency |
1.7kHz |
| Amplifier requirements |
10 - 100 W |
| Sensitivity (2.83V/1m) |
90dB (wall mount)
87dB (floor stand mount) |
| Maximum output (SPL) |
107dB |
| Impedance |
8Ω |
| Internal volume |
0.7 Litres |
| Weight |
1kg (2.2lbs) |
Dimensions
(H x W x D) |
330* x 140 x 35 mm
(13.0 x 5.5 x 1.4 in.) |
Dimensions
(H x W x D)
centre mode |
140 x 330 x 35 mm
(5.5 x 13.0 x 1.4 in.) |
| * Height of satellites will increase by 30mm when using supplied desk stand |
| |
|
| T-2 |
|
| Design |
Closed box powered subwoofer |
| Drive units |
1 x 250mm (10in.) |
| Frequency response |
30Hz - 250Hz |
| Amplifier |
250 Watts built-in Class-D |
| Maximum output (SPL) |
110dB |
| Low pass filter variable |
Fixed 250Hz, 2nd-order |
| Low level signal inputs |
RCA phono socket |
| Internal volume |
12.7 Litres |
| Power requirements |
100 - 240 V ac ~ 50/60Hz |
| Power consumption |
250VA |
| Weight |
13kg (28.6lbs) |
Dimensions
(H x W x D) |
380 x 370 x 177 mm
(15.0 x 14.6 x 7.0 in.) |
