Model |
Ci160CRds |
Nominal impedance |
8Ohm |
Sensitivity (2.83V @ 1m) |
91dB |
Frequency response +/-6dB open-backed |
50Hz - 20kHz |
Crossover frequency |
3.2kHz |
Drive units |
LF: Dual voice coil 160mm MF: - HF: 2 x 19mm (0.75in.)
|
Recommended amplifier power |
10-80W |
Product external dimensions |
Diameter Ø: 234.6mm (9.24in.) Depth: 93mm (3.66in.) |
Cut-out dimension |
Diameter Ø: 196mm (7.71in.) |
Mounting depth from surface |
Product only: 86mm (3.36in.) |
Optional rough in frame |
RIF160R |
